In each model of the CA series, a 2U national standard rack is used, covering the power range of 150 to 1200 watts. Excellent circuit design and a complete set of rack design make the CA series sturdy and durable, which is more cost-effective for any permanent audio installation system solution.
CA-350II power amplifier is a classic analog power amplifier, adopts class AB circuit design, mature and stable, suitable for various harsh environments, and can achieve trouble-free operation. There are a variety of configurations, power levels and functions to choose from, which can almost meet the needs of all commercial applications which includes a lot of comprehensive protection circuit of CA power amplifier. In view of the high temperature environment that is unfavorable to the machine when the power amplifier is working, the built-in audio limiter, start-up delayer and peak current limiter of the CA series power amplifier provide comprehensive protection.
| Nominal Parameters | |
| RMS output power | 2 x 210W/8Ω; 2 x 350W/4Ω; 2 x 500W/2Ω; |
| Bridge output power | 700W/8Ω; 950W/4Ω |
| Circuit principle | class AB |
| Input sensitivity | 1V, rated power output at 1KHz |
| Selectable input sensitivity | 0.775V/1V/1.4V |
| Input impedance | 20KΩ balance & 10KΩ unbalance |
| S/N Ratio | ≥100 dB |
| THD+N | ≤0.01% rated power at 8Ω at 1KHz |
| Damping factor | ≥500, 8Ω at 1KHz |
| Slew rate | 36V/µs at Stereo mode |
| Frequency response | 20Hz~20KHz, +3/0dB |
| Protections | Comprehensive short circuit, open circuit, overheating, UHF and RF protection |
| Cooling | Automatic variable speed fan, front exhaust |
| Power supply | 200-240VAC, 50/60Hz |
| Chassis | 2U extreme steel with stainless coating |
| Connector | Female XLR for input, Male XLR for link; speakON and binding post for output |
| Weight | 15.25kg |
| Dimension | 483 x 364 x 89mm (W x D x H) |
Unit : mm
